| Processor |
12th Gen Intel® Core™ i3-1210U
12th Gen Intel® Core™ i5-1240U, vPro
12th Gen Intel® Core™ i7-1260U, vPro |
| Operating System |
Microsoft® Windows 11 2022H2 Pro
Microsoft® Windows 11 2021H2 Pro |
| Memory |
8 GB LPDDR5 5200MT/s integrated
16 GB LPDDR5 5200MT/s integrated
32 GB LPDDR5 5200MT/s integrated |
| Chipset |
Intel® ADL-P PCH |
| Intel Responsiveness Technologies |
Intel® Rapid Storage Technology |
| Video Card |
Intel® Iris® Xe Graphics (Integrated) for i5 and i7
Intel UHD Graphics (Integrated) for i3 |
| Monitor |
10" 16:10 FHD (1920 x 1200) @ 60 Hz, sRGB 100%, Water/Glove-Capable Touchscreen, Anti-Glare and Anti-Smudge, Polarizer, Corning® Gorilla® Glass, 1000 Nit Outdoor-Readable, Active Pen Support, Passive Pen Support |
| Storage |
SSD M.2 2230 PCIe/NVMe Class 35 256 GB
SSD M.2 2230 PCIe/NVMe Class 35 512 GB
SSD M.2 2230 PCIe/NVMe Class 35 1 TB
SSD M.2 2230 PCIe/NVMe Class 25 2 TB
SED M.2 2230 PCIe/NVMe Class 35 256 GB
SED M.2 2230 PCIe/NVMe Class 35 512 GB |
| Security |
TPM 2.0 FIPS-140-2 Certified / TCG Certified
Control Vault 3 Advanced Authentication with FIPS 140-2 Level 3 Certification
FIPS (Federal Information Processing Standards) 140-2 certification for TPM
Fingerprint Reader with Control Vault 3
Contacted Smart Card and Control Vault 3
Self Encrypting Drive (SED), Opal 2.0 only - PCIe Interface
Chassis Intrusion Detection
Battery Removal Detection
RPMC SPI flash
SPI Flash Tamper Detection/Prevention
Shunt Circuit
Wedge-shaped lock slot (Optional)
Contacted Smart Card, NFC, and Control Vault 3
Dell Support Assist
Dell Optimizer
Dell SafeBIOS
Dell Encryption Enterprise
Dell Encryption Personal
Intel Authenticate with IPT
Intel Platform Trust Technology
Intel Boot Guard
Intel Software Guard (SGX)
Intel Trusted Execution Technology (TXT)
Intel Total Memory Encryption Multi-Key (TME) (Optional)
Dell Data Security and Management Software
Dell Endpoint Security and Management Software
Dell Secured Component Verification (availability varies by region, additional purchase required)
Dell SafeID (additional purchase required) |
| Docking |
Dell USB-C Dock - WD19S 130W
Vehicle docks |
| Optical Drive |
No optical drive |
| Camera |
No camera / No microphone
User Facing Camera: 5M RGB/VGA IR Camera
World Facing Camera: 11M RGB Camera |
| Audio |
Stereo speakers with Waves MaxxAudio® Pro L/R each 2W (Realtek® ALC3254) |
| Battery |
Internal 4-Cell, 36 Wh (800 Wh/L) Lithium Ion Battery, ExpressCharge™
Optional Dual 2-Cell, 18 Whr (36 Wh total 800Wh/L) Lithium Ion replaceable, dual hot-swappable Long Life cycle versions Optional |
| Power |
65W adapter, USB-C
90W adapter, USB-C, MIL 461F |
| Wireless |
Intel® Wi-Fi 6E (2.4/5/6 GHz) AX211 2x2, 802.11ax with MIMO + Bluetooth 5.2
Qualcomm® Wi-Fi 6E (2.4/5/6 GHz) WCN6856-DBS 2x2, 802.11ax with MIMO + Bluetooth 5.3 |
| Mobile Broadband |
Dell Global 5G (DW5931E), eSIM/SIM |
| Gps |
uBlox NEO-M9N, L1 (1575.42 MHz) |
| Ports |
2 x Type-C Thunderbolt 4 ports with Power Delivery (Internal battery Option)
2 x USB4 DisplayPort Type-C ports with Power Delivery (Hot Swap Battery Option)
1 x USB 3.2 Gen 1 Type-A port with PowerShare (Optional)
Expansion I/O Port (top) (Choose from Barcode Scanner, USB 3.2 Gen 1 Type-A, Universal Audio Jack, RJ45 1Gbit Ethernet) |
| Slots |
1 x Micro SD card slot
1 x Micro SIM card slot (Dual battery configurations only)
1 x Wedge-shaped lock slot (Optional)
1 x Smart card reader slot
1 x NFC reader, Non-slot |
| Chassis |
Plastic resin and thermoplastic elastomer (TPE) |
| Dimensions And Weight |
Width: 262.50mm / 10.335"
Height: 25.4 mm / 1.00"
Depth: 188 mm / 7.402"
Starting weight: 1.016 kg / 2.24 lbs
Maximum weight (with handle): 1.284 kg / 2.83 lbs |
| Input |
Rugged 7030 Tablet Water/Glove-Capable Touchscreen
Dell Rugged Active Pen - PN720R (Sold separately)
Rugged 7030 Tablet Premium Keyboard (Sold separately) |
| Sensors |
Hall Sensor, Gyroscope, eCompass/Magnetometer, Accelerometer (free fall), Ambient Light Sensor, Proximity Sensor (SAR) |
